Protocol Gateway Enables Communication Between Siemens S7-1500 and Rockwell PLCs in Welding Line Ret

August 21, 2026 | Industrial Automation & Automotive Manufacturing

Automotive component manufacturers are increasingly upgrading existing production lines with digital control, robotics, and connected automation systems. However, many plants still operate mixed-vendor equipment accumulated over years of production. Siemens PLCs may coexist with Rockwell Automation controllers, industrial robots, servo drives, frequency converters, and other devices from different suppliers.

This multi-vendor environment can create significant communication challenges, particularly when equipment relies on different industrial Ethernet protocols.

A recent welding production line retrofit illustrates how an industrial protocol gateway can provide a practical way to connect a Siemens S7-1500 PLC using PROFINET with Rockwell-based equipment using EtherNet/IP, allowing existing automation assets to exchange process data without replacing the entire control system.

Communication Challenges in Multi-Vendor Welding Lines

In automotive component welding applications, the PLC is typically responsible for coordinating production sequences, robot operations, safety-related interlocks, process parameters, and equipment status.

A Siemens S7-1500 PLC can communicate with field devices through PROFINET, while many Rockwell Automation PLCs and associated industrial equipment use EtherNet/IP.

Although both are industrial Ethernet technologies, PROFINET and EtherNet/IP are different communication systems with their own device models, communication mechanisms, configuration methods, and data structures.

As a result, simply connecting two devices with an Ethernet cable does not automatically make them capable of exchanging application data.

For a welding production line, this can create several practical problems:

• PLC commands cannot be exchanged directly between different protocol networks.

• Equipment status and fault information may not be available to the main controller.

• Robot and drive operating parameters can become isolated from the central PLC.

• Production data may require additional communication interfaces or custom programming.

• Existing automation equipment becomes difficult to integrate into a new control architecture.

For manufacturers upgrading an existing production line, replacing all legacy controllers and field devices is often neither technically necessary nor economically attractive.

Traditional Retrofit Methods Can Increase Project Complexity

A conventional approach to cross-platform integration may involve replacing communication modules, installing additional PLC hardware, modifying existing control programs, or converting large amounts of data into hardwired I/O signals.

While these methods can work in specific applications, they may introduce additional engineering effort.

Replacing communication hardware can require changes to the existing PLC architecture. Replacing field controllers or robots can increase project cost and extend commissioning time. Hardwired I/O communication, meanwhile, requires additional cables, terminals, I/O modules, and electrical interfaces.

For a production line that already contains functioning automation equipment, a less disruptive approach is often preferred.

This is where a PROFINET to EtherNet/IP protocol gateway can become useful.

How a PROFINET to EtherNet/IP Gateway Works

A protocol gateway operates as a communication bridge between two industrial networks.

On the PROFINET side, the gateway communicates with the Siemens S7-1500 PLC according to the configured PROFINET device architecture. On the EtherNet/IP side, it exchanges data with compatible EtherNet/IP controllers or devices.

The gateway then maps data between the two networks.

A simplified communication structure can be represented as:

Siemens S7-1500 PLC → PROFINET → Protocol Gateway → EtherNet/IP → Rockwell PLC / Robot / Drive

Data can be mapped according to the requirements of the application.

For example, signals from the Siemens PLC may include:

• Start and stop commands

• Automatic/manual operating modes

• Production recipe numbers

• Welding process parameters

• Reset commands

• Production sequence information

Data returned from the EtherNet/IP network may include:

• Equipment running status

• Ready signals

• Fault and alarm information

• Robot status

• Drive status

• Production feedback

• Diagnostic information

The exact data mapping depends on the gateway model, PLC configuration, connected devices, and application requirements.

Simplifying Siemens and Rockwell PLC Integration

For an automotive welding line, the main benefit of this architecture is that it can reduce the need for extensive changes to existing equipment.

The Siemens S7-1500 can remain responsible for the main production control strategy, while Rockwell-based equipment can continue operating within its existing EtherNet/IP environment.

Instead of redesigning the complete automation system, engineers can establish a defined data exchange interface through the protocol gateway.

This approach can be particularly useful when a production line contains:

• Siemens S7-1200 or S7-1500 PLC systems

• Rockwell Automation PLCs

• Industrial robots

• Servo systems

• Variable frequency drives

• Welding controllers

• Remote I/O stations

• Other EtherNet/IP field devices

The gateway does not replace the PLC or robot controller. Its primary function is to provide communication interoperability between otherwise incompatible industrial networks.

Data Mapping Is the Key Engineering Step

Successful protocol conversion depends heavily on correct data mapping.

Before commissioning, engineers normally need to define which data must be transferred between the PROFINET and EtherNet/IP networks.

For example, a data table may contain:

The actual memory addresses, data types, byte order, array structures, and communication sizes must be configured according to the selected gateway and connected controllers.

This engineering step is particularly important when exchanging integer, floating-point, Boolean, or structured process data.

Advantages for Existing Production Line Retrofits

For brownfield automotive manufacturing projects, protocol gateways offer several potential advantages.

Preserve Existing Equipment

A gateway can allow existing PLCs, robots, and drives to remain in service rather than requiring wholesale replacement.

Reduce Hardwired Signal Conversion

Digital communication can replace large numbers of individual hardwired signals where the application permits, reducing wiring complexity and simplifying signal management.

Improve Data Availability

Process status, alarms, commands, and production parameters can be exchanged between previously isolated automation networks.

Support Gradual Modernization

Manufacturers can upgrade the control architecture in stages instead of replacing the entire production line at once.

Reduce Integration Complexity

A dedicated communication interface can provide a defined boundary between different industrial Ethernet systems, making the overall architecture easier to manage.

A Practical Architecture for Automotive Welding Applications

A typical retrofit architecture can use the Siemens S7-1500 as the central production controller.

The PLC communicates with the protocol gateway through PROFINET. The gateway establishes the corresponding EtherNet/IP communication interface with Rockwell Automation equipment and other compatible field devices.

The resulting architecture allows production information to move between the two automation domains while maintaining their respective communication environments.

For example:

Production Management Layer

↓

Siemens S7-1500 Main PLC

↓ PROFINET

PROFINET / EtherNet-IP Protocol Gateway

↓ EtherNet/IP

Rockwell PLC / Welding Controller / Robot / Drive

This architecture can provide a practical foundation for integrating heterogeneous equipment in automotive welding, assembly, material handling, and other discrete manufacturing applications.

What Engineers Should Verify Before Selecting a Gateway

Not every PROFINET-to-EtherNet/IP gateway supports the same network roles or data structures. Engineers should therefore verify the technical requirements before selecting hardware.

Important specifications include:

• PROFINET controller/device role

• EtherNet/IP scanner/adapter role

• Supported I/O data size

• Cyclic data exchange capability

• Acyclic or explicit messaging support

• PLC engineering software compatibility

• Data mapping flexibility

• Diagnostic functions

• Industrial Ethernet port configuration

• Electrical and environmental specifications

• Configuration and commissioning software

• Supported firmware versions

The gateway should also be evaluated against the actual PLC and device configuration rather than selected solely according to the protocol names printed on the product datasheet.

Conclusion

Mixed-vendor automation is becoming increasingly common in automotive manufacturing. As production lines evolve, Siemens PLCs, Rockwell controllers, robots, drives, welding equipment, and other industrial devices may need to operate together despite using different communication protocols.

A PROFINET to EtherNet/IP protocol gateway provides one practical approach to this integration challenge.

By creating a controlled communication bridge between the Siemens S7-1500 and EtherNet/IP equipment, manufacturers can exchange key production and equipment data while preserving more of their existing automation investment.

For brownfield welding line modernization, this type of protocol conversion can support a more gradual and flexible migration strategy, helping manufacturers connect legacy and new automation equipment without immediately redesigning the entire production architecture.
