OVATION 1X00781H01L | Analog Input Module Unbelievable Prices

Overview

The OVATION 1X00781H01L is an analog input module used in Emerson’s Ovation distributed control system. It converts signals from field sensors into digital data for the Ovation controller, enabling precise monitoring of industrial process variables.

General Information

Part Number: 1X00781H01L
Manufacturer: Emerson
Country of Origin: USA
Module Type: Analog Input Module
Application: Converts analog signals from sensors such as temperature, pressure, and flow into digital data for process control

Power Specifications

Supply Voltage: 24 V DC
Power Consumption: Approximately 10 W
Protection: Provides overload and short-circuit protection for connected sensors

Communication & Interface

Interface: Ovation system backplane
I/O Capacity: Supports multiple analog input channels depending on configuration
Diagnostics: Monitors signal integrity and detects faults in input channels

I/O & Channels

Analog Inputs: Multiple channels for 4–20 mA or 0–10 V signals
Digital Outputs: None
External Load Support: Not applicable, module is for signal acquisition only

Environmental

Operating Temperature: −40 to +70 °C
Humidity: Up to 95% RH, non-condensing
Mounting: Rack or cabinet installation in Ovation control systems

Dimensions & Weight

Dimensions (L × W × H): 140 × 60 × 25 mm
Weight: ~0.3 kg

Brand-new originals in stock, customer service 24/7, transparent pricing and rapid quotes.
