Overview
The Ovation 1X00046H01 is a media converter module designed for Emerson’s Ovation DCS. It provides conversion between copper-based communication signals and fiber-optic signals, allowing long-distance transmission and improved noise immunity in industrial control networks.
General Information
Part Number: 1X00046H01
Manufacturer: Emerson
Brand / Country of Origin: Emerson / USA
Type: Media Converter / Network Interface Module
Series: Ovation Communication Modules
Mounting: Installed on an Ovation rack or backplane
Technology: Copper-to-fiber or fiber-to-copper signal conversion
Power Specifications
Supply Voltage: Powered through Ovation system backplane (nominal 24 V DC distribution)
Power Consumption: Low, typical of communication modules
Protection: Internal surge protection and signal isolation
Indicators: LED indicators for power, link, and communication status
Communication & Interface
Signal Type: Copper network signal and fiber-optic signal
Function: Extends communication distance and reduces electromagnetic interference
Interfaces: Standard copper interface and optical fiber port
Diagnostics: LED indication of link status and communication activity
Configuration: No field configuration required; operates when inserted
Environmental
Operating Temperature: 0 to +60 °C
Humidity: Up to 95% RH, non-condensing
Installation Conditions: Indoor control cabinet or protected rack environment
Dimensions & Weight
Dimensions (L × W × H): Approx. 165 × 35 × 120 mm
Weight: ~0.30 kg
