Overview
The Ovation 1X00046H02 is a media converter module used in Emerson’s Ovation DCS. It converts copper-based communication signals to fiber-optic signals, supporting long-distance data transmission and enhancing noise immunity in industrial environments.
General Information
Part Number: 1X00046H02
Manufacturer: Emerson
Brand / Country of Origin: Emerson / USA
Type: Media Converter / Network Interface Module
Series: Ovation Communication Series
Mounting: Plug-in installation on Ovation rack or backplane
Technology: Copper-to-fiber or fiber-to-copper communication conversion
Power Specifications
Supply Voltage: Powered through Ovation backplane (nominal 24 V DC distribution)
Power Consumption: Low, consistent with standard communication interface modules
Protection: Internal isolation and surge suppression
Indicators: LEDs for power, link status, and communication activity
Communication & Interface
Function: Converts electrical (copper) signals to optical fiber signals and vice versa
Copper Interface: Standard Ovation or Ethernet-type communication signal
Fiber Interface: Optical communication port for long-distance transmission
Benefits: Reduces electromagnetic interference, increases communication range
Diagnostics: LED indication of link state and data activity
Configuration: No manual configuration required; auto-recognized by the system
Environmental
Operating Temperature: 0 to +60 °C
Humidity: Up to 95% RH, non-condensing
Installation Environment: Indoor control cabinets and protected rack enclosures
Dimensions & Weight
Dimensions (L × W × H): Approx. 165 × 35 × 120 mm
Weight: ~0.30 kg
Brand-new original units, available immediately with full customer support access.
