OVATION 1X00691H01 | Digital Output Module Recommended products

Overview
The Ovation 1X00691H01 is a digital output module used in the Emerson Ovation DCS. It accepts digital signals from the control system and drives discrete field devices such as relays, actuators, indicators or contactor coils — enabling control and actuation in industrial processes.

General Information
Part Number: 1X00691H01
Manufacturer: Emerson
Brand / Country of Origin: Emerson / USA
Series: Ovation I/O Modules
Type: Digital Output Module
Mounting: Plug-in module in standard Ovation I/O rack or chassis slot
Output Type: 24 V DC discrete output signals (or compatible output signals per system design)
Channel Count: 32 output channels (typical for this module)

Power Specifications
Module Power Supply: Powered via Ovation I/O rack backplane (standard system bus power)
Output Signal Power: Provides discrete output drives for field devices — the driving current depends on load requirements but module designed to supply typical industrial digital loads
Protection: Output isolation and protection circuits to guard against overload and short circuits
Indicators: Module may support rack front-panel LEDs or status indicators to show output channel state and fault condition (depending on system configuration)

Communication & Interface
Function: Converts control logic signals from the system to discrete on/off outputs for field devices
Interface: Communicates with central controller via Ovation backplane bus; receives digital command signals and outputs correspondingly
Output Handling: Provides basic discrete control; not intended for analog signaling or complex modulation
Compatibility: Compatible with standard Ovation I/O and controller modules in same rack configuration

Environmental
Operating Temperature: 0 to +60 °C (normal industrial control cabinet ambient)
Humidity: Up to 95% RH, non-condensing
Installation Environment: Indoor control cabinets or protected rack enclosures

Dimensions & Weight
Dimensions  (L × W × H): 165 × 35 × 120 mm
Weight: ~0.35 kg (module only)

We provide brand-new, high-quality original parts, all in stock with immediate pricing.
