Schneider TM5SDI12D Discrete Input Module

Overview

The Schneider TM5SDI12D is a compact discrete input module designed for the Modicon TM5 I/O system. It provides reliable digital signal acquisition from field devices such as sensors, switches, and control components, enabling efficient monitoring and machine control.

With its compact structure and flexible integration capability, the module is suitable for industrial automation systems requiring accurate input signal collection and modular I/O expansion.

General Information

Part Number: TM5SDI12D

Manufacturer: Schneider Electric

Brand: Schneider Electric

Country of Origin: France

Series: Modicon TM5

Type: Discrete Input Module

Application: Machine automation, industrial control, distributed I/O systems

Mounting: TM5 bus base installation

Design: Compact modular I/O unit with integrated diagnostic functions

Power Specifications

Supply Voltage: 24 V DC

Power Supply Type: Powered through the TM5 I/O system

Input Channels: 12 digital input channels

Input Signal Type: Discrete voltage signals

Signal Detection: Fast and reliable digital signal acquisition

Protection: Input protection against electrical interference and overload conditions

Indicators: LED status indicators for channel and module diagnostics

Communication & Interface

System Interface: Modicon TM5 expansion bus

Communication Method: Internal TM5 bus communication with controller

Input Configuration: Software-configurable input parameters

Diagnostics: Module status monitoring, input fault detection, and signal monitoring

Connection Type: TM5 terminal block interface

Application Support: Supports connection with industrial sensors, switches, and field devices

Environmental

Operating Temperature: 0 to +55 °C

Storage Temperature: −25 to +70 °C

Humidity: 10 to 95% RH, non-condensing

Protection Rating: IP20

Installation Environment: Industrial control cabinets and automation panels

Environmental Resistance: Designed for reliable operation in industrial environments

Dimensions & Weight

Dimensions (L × W × H): 99 × 12.5 × 75 mm

Weight: 0.025 kg
