Schneider STBXBE2100K Bus Expansion Kit

Overview

The Schneider STBXBE2100K is a bus expansion kit designed for Modicon STB distributed I/O systems. It provides the components required to extend the system bus and support additional STB modules in industrial automation applications.

General Information

Part Number: STBXBE2100K

Manufacturer: Schneider Electric

Series: Modicon STB

Type: Bus Expansion Kit

Module Category: System Bus Expansion

Application: Distributed I/O and industrial automation systems

Brand: Schneider Electric

Country of Origin: France

Power Specifications

Supply Voltage: 24 V DC system environment

Power Type: DC power system

Power Consumption: Dependent on the connected STB system configuration

Power Management: Supports bus expansion within the distributed I/O architecture

Communication & Interface

Bus Function: Extends the STB system bus for additional modules

System Interface: Modicon STB backplane and bus architecture

Module Connection: Supports connection between expanded STB system segments

Communication: Facilitates data and system communication across the expanded bus

Status Indication: System status can be monitored through the connected STB network interface

Environmental

Operating Temperature: Suitable for standard industrial environments

Storage Temperature: Suitable for protected industrial storage conditions

Humidity: Suitable for normal industrial humidity conditions

Installation Environment: Industrial control cabinets and electrical enclosures

Protection: Intended for installation in a protected control-panel environment

Dimensions & Weight

Dimensions (L × W × H): 120 × 18.4 × 70 mm

Weight: 0.3 kg

Efficient Bus Expansion for Flexible Automation Systems
