Schneider STBACI1225K Basic Analog Input Kit

Overview

The Schneider STBACI1225K is a Basic Analog Input Kit designed for the Modicon STB distributed I/O platform. It provides accurate analog signal acquisition for industrial automation systems, allowing field devices such as sensors and transmitters to be connected with reliable data processing.

Its compact modular design makes it suitable for space-saving control cabinets, machine automation systems, and process monitoring applications that require stable analog input performance.

General Information

Part Number: STBACI1225K

Manufacturer: Schneider Electric

Brand: Schneider Electric

Country of Origin: France

Series: Modicon STB

Type: Basic Analog Input Kit

Function: Analog signal input and data acquisition module

Application: Industrial automation, process control, and distributed I/O systems

Mounting: DIN rail installation within Modicon STB island architecture

Design: Compact plug-in module structure for easy system integration and maintenance

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: Approx. 0.5 W

Input Type: Analog voltage and current input

Signal Conversion: Converts field analog signals into digital data for controller processing

Protection: Integrated input protection for enhanced system reliability

Status Indicators: LED indicators for power, communication, and diagnostic status

Communication & Interface

System Connection: Modicon STB island bus interface

Communication Method: Internal bus communication with STB network interface modules

Input Channels: Analog input channels for industrial measurement devices

Signal Interface: Compatible with standard analog field signals

Configuration: Software-based module parameter setup

Diagnostics: Channel monitoring, fault detection, and operating status feedback

Environmental

Operating Temperature: 0 to +60 °C

Storage Temperature: −40 to +85 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20

Installation Environment: Suitable for industrial control cabinets and automation panels

Dimensions & Weight

Dimensions (L × W × H): 13.9 × 128.3 × 70 mm

Weight: 0.02 kg
