Schneider TM5ACBM05R Bus Base With Address

Overview

The Schneider TM5ACBM05R is a Bus Base With Address designed for the Modicon TM5 distributed I/O system. It provides the mechanical support, electrical connection, and addressing function required for connecting TM5 electronic modules within an automation system.

With integrated addressing capability and a compact modular design, the TM5ACBM05R helps simplify I/O configuration, system expansion, and reliable communication between connected modules.

General Information

Part Number: TM5ACBM05R

Manufacturer: Schneider Electric

Brand: Schneider Electric

Country of Origin: France

Series: Modicon TM5

Type: Bus Base With Address

Function: Module connection, addressing, and internal bus communication support

Application: Industrial automation, machine control, and distributed I/O systems

Mounting: DIN rail installation within TM5 modular I/O architectures

Design: Compact modular base unit with integrated addressing features

Power Specifications

Supply Voltage: 24 V DC system power

Power Distribution: Provides internal power and communication connection between TM5 modules

Power Consumption: Low-power passive module operation

Protection: Designed for stable electrical connection and industrial reliability

Addressing Function: Provides module identification within the TM5 system configuration

Communication & Interface

System Connection: Modicon TM5 internal bus interface

Communication Method: Internal data exchange between connected TM5 modules

Address Configuration: Integrated module addressing for system identification

Module Support: Compatible with TM5 electronic I/O modules

Diagnostics: Supports system-level status monitoring through controller configuration

Environmental

Operating Temperature: 0 to +55 °C

Storage Temperature: −25 to +70 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20

Installation Environment: Suitable for industrial control cabinets and automation equipment panels

Dimensions & Weight

Dimensions (L × W × H): 25 × 73.5 × 90 mm

Weight: 0.02 kg
