Schneider TM5ACBM12 Bus Base Module

Overview

The Schneider TM5ACBM12 is a Bus Base Module designed for the Modicon TM5 distributed I/O system. It provides the mechanical support and electrical connection interface required for installing TM5 electronic modules within industrial automation architectures.

With a compact modular structure, the TM5ACBM12 enables efficient system expansion, reliable internal communication, and simplified maintenance for machine control and automation applications.

General Information

Part Number: TM5ACBM12

Manufacturer: Schneider Electric

Brand: Schneider Electric

Country of Origin: France

Series: Modicon TM5

Type: Bus Base Module

Function: Module mounting and internal bus connection

Application: Industrial automation, machine control, and distributed I/O systems

Mounting: DIN rail installation within TM5 modular I/O configurations

Design: Compact modular base unit for flexible system assembly and expansion

Power Specifications

Supply Voltage: 24 V DC system power

Power Distribution: Provides internal power and signal connection between TM5 modules

Power Consumption: Low-power passive module operation

Electrical Interface: Supports reliable power and communication distribution within the I/O system

Protection: Designed for stable industrial connection and long-term operation

Communication & Interface

System Connection: Modicon TM5 internal bus interface

Communication Method: Internal data exchange between connected TM5 modules

Module Support: Compatible with TM5 electronic I/O modules

Installation Interface: Mechanical and electrical connection interface for modular expansion

Diagnostics: Supports system-level status monitoring through connected modules

Environmental

Operating Temperature: 0 to +55 °C

Storage Temperature: −25 to +70 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20

Installation Environment: Suitable for industrial control cabinets and automation equipment panels

Dimensions & Weight

Dimensions (L × W × H): 25 × 73.5 × 90 mm

Weight: 0.02 kg
