Schneider TM5ACBM3FS Security Encoding Bus Base

Overview

The Schneider TM5ACBM3FS is a security encoding bus base designed for the Modicon TM5 modular automation platform. It provides secure mechanical connection and module identification functions, helping prevent incorrect module installation while maintaining reliable communication within the TM5 system.

This bus base is suitable for industrial automation applications where modular I/O expansion, system reliability, and enhanced installation safety are required.

General Information

Part Number: TM5ACBM3FS

Brand: Schneider Electric

Country of Origin: France

Series: Modicon TM5

Type: Security Encoding Bus Base

Function: Provides secure module mounting and bus connection with coding protection

Application: Industrial automation, machine control, modular I/O systems

Mounting Method: DIN rail installation

Design: Compact modular structure with security encoding features for reliable system assembly

Power Specifications

Supply Voltage: 24 V DC system power

Power Source: Supplied through the TM5 modular bus system

Power Distribution: Supports internal power and signal transmission between connected modules

Power Management: Designed for stable operation in distributed automation systems

Protection Features: Helps reduce installation errors through mechanical coding and secure module positioning

Status Indication: Supports system diagnostics through controller monitoring and module indicators

Communication & Interface

Bus Interface: TM5 internal expansion bus

Communication Function: Enables communication between controller, bus base, and connected TM5 modules

Connection Type: Modular backplane bus connection

System Compatibility: Compatible with Schneider Electric Modicon TM5 I/O components

Diagnostics: Supports module identification and system status monitoring

Environmental

Operating Temperature: -10 to +60 °C

Storage Temperature: -25 to +70 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20

Installation Environment: Designed for use inside industrial control cabinets

Application Conditions: Suitable for standard industrial automation environments

Dimensions & Weight

Dimensions (L × W × H): 99 × 38 × 75 mm

Weight: 0.058 kg
