Schneider TM5ACBN1 Bus Base Module

Overview

The Schneider TM5ACBN1 is a bus base module designed for the Modicon TM5 modular automation system. It provides a reliable mechanical base and internal bus connection for TM5 expansion modules, supporting flexible I/O configurations and efficient system integration.

This module is widely used in industrial machine control applications where compact design, easy installation, and dependable module communication are required.

General Information

Part Number: TM5ACBN1

Brand: Schneider Electric

Country of Origin: France

Series: Modicon TM5

Type: Bus Base Module

Function: Provides module mounting support and internal communication connection for TM5 I/O modules

Application: Industrial automation, machine control, distributed I/O systems

Mounting Method: DIN rail installation

Design: Modular structure for simple expansion, replacement, and maintenance

Power Specifications

Supply Voltage: 24 V DC system power

Power Source: Supplied through the TM5 bus system

Power Distribution: Supports internal power and signal distribution between connected modules

Power Management: Designed for stable operation within modular automation architectures

Protection Features: Ensures secure electrical connection and reliable module operation

Status Indication: Supports system monitoring through controller diagnostics

Communication & Interface

Bus Interface: TM5 internal expansion bus

Communication Function: Enables data exchange between controller and connected TM5 modules

Connection Type: Modular backplane bus connection

System Compatibility: Designed for Schneider Electric Modicon TM5 automation components

Diagnostics: Supports system status monitoring and module identification

Environmental

Operating Temperature: -10 to +60 °C

Storage Temperature: -25 to +70 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20

Installation Environment: Suitable for installation inside industrial control cabinets

Application Conditions: Designed for standard industrial automation environments

Dimensions & Weight

Dimensions (L × W × H): 99 × 38 × 75 mm

Weight: 0.132 kg
