Schneider TM5ACLPR10 Busbar Base Right Side Fixing Plate

Overview

The Schneider TM5ACLPR10 is a busbar base right side fixing plate designed for the Modicon TM5 modular automation system. It provides mechanical support and secure positioning for the right side of the TM5 busbar assembly, helping maintain stable module alignment and reliable system installation.

This component is suitable for industrial automation cabinets where precise module arrangement, secure mounting, and long-term system stability are required.

General Information

Part Number: TM5ACLPR10

Brand: Schneider Electric

Country of Origin: France

Series: Modicon TM5

Type: Busbar Base Right Side Fixing Plate

Function: Provides right-side mechanical fixing and support for TM5 busbar assemblies

Application: Industrial automation, modular I/O systems, machine control panels

Mounting Method: DIN rail and modular system installation

Design: Compact structural component for secure TM5 system assembly

Power Specifications

Power Supply: Not required

Electrical Function: Passive mechanical support component

Power Consumption: 0 W

System Role: Maintains correct positioning and stability of busbar components without electrical operation

Protection Features: Supports reliable mechanical installation within the automation system

Communication & Interface

Interface Type: Mechanical busbar fixing connection

Communication Function: None

System Integration: Designed for use with Schneider Electric Modicon TM5 modular components

Connection Method: Secure mechanical attachment within the TM5 assembly structure

Application Role: Provides alignment and fixing support for connected modules

Environmental

Operating Temperature: -10 to +60 °C

Storage Temperature: -25 to +70 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20

Installation Environment: Suitable for industrial control cabinets and automation equipment

Application Conditions: Designed for standard industrial operating environments

Dimensions & Weight

Dimensions (L × W × H): 99 × 38 × 75 mm

Weight: 0.05 kg
