Schneider TM5ACTB12 Terminal Blocks

Overview

The Schneider TM5ACTB12 is a terminal block designed for the Modicon TM5 modular automation system. It provides a secure and organized wiring interface for connecting field signals, power lines, and external devices to TM5 I/O modules.

This compact terminal component supports efficient cabinet wiring, quick module replacement, and reliable electrical connections in industrial automation applications.

General Information

Part Number: TM5ACTB12

Brand: Schneider Electric

Country of Origin: France

Series: Modicon TM5

Type: Terminal Block

Function: Provides plug-in wiring connection for TM5 I/O modules

Application: Industrial automation, machine control, distributed I/O systems

Connection Method: Removable terminal connection

Design: Compact modular structure for easy installation and maintenance

Power Specifications

Rated Voltage: 24 V DC system applications

Electrical Function: Provides signal and power wiring connection points

Power Distribution: Supports field wiring connection between external devices and automation modules

Current Handling: Designed for standard TM5 I/O module requirements

Protection Features: Ensures stable electrical contact and reliable signal transmission

Communication & Interface

Interface Type: Plug-in terminal interface

Connection Points: Supports multiple field wiring connections

Communication Function: Passive terminal component without independent communication capability

System Compatibility: Compatible with Modicon TM5 modular I/O components

Installation Feature: Enables convenient wiring, replacement, and system maintenance

Environmental

Operating Temperature: -10 to +60 °C

Storage Temperature: -25 to +70 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20

Installation Environment: Suitable for industrial control cabinets and automation equipment

Application Conditions: Designed for standard industrial operating environments

Dimensions & Weight

Dimensions (L × W × H): 80 × 24 × 14 mm

Weight: 0.02 kg
