Overview
The Triconex 9561-810 is a digital input termination panel designed for use with 115V AC digital input modules in Tricon v9 and v10 systems. It provides 16 input points with commoned power terminals (PWR+ and PWR–), each protected by a 1A slow-blow fuse with a blown-fuse indicator. This panel is compatible with 32-point digital input modules, requiring two panels for each module.

General Information

• Model Number: 9561-810

• Type: Digital Input Termination Panel

• Compatibility: Tricon v9 and v10 systems

• Country of Origin: USA

Power Specifications

• Operating Voltage: 115V AC

• Power Terminals: Commoned (PWR+ and PWR–)

• Leakage Current per Point:

• Maximum: 3.3 mA

• Typical: 2.5 mA

• Fuse Protection: 1A slow-blow fuse with LED indicator

• Reason: Because stable and protected power ensures reliable operation in industrial environments.

Communication & Interface

• Interface Type: Terminal block connections for field wiring

• Number of Input Points: 16

• Function: Facilitates secure and organized wiring for digital input signals from field devices to the Tricon controller.

• Modules Compatible:

• 3501E: 32-point, 115V AC/DC, non-commoned, isolated, TMR

• 3501T: 32-point, 115V AC/DC, non-commoned, isolated, TMR

• Usage: Two termination panels are required for each 32-point module.

Environmental

• Operating Temperature Range: 0°C to 60°C

• Storage Temperature Range: -40°C to 85°C

• Humidity: 0% to 95% RH, non-condensing

• Protection Rating: IP45

• Reason: Because robust environmental tolerance ensures reliable operation in industrial settings.

Dimensions & Weight

• Dimensions: 200  x  60  x  40  mm

• Weight: Approximately 0.5 kg
