Overview
The Yokogawa ADV869-P01 is an I/O interface module designed for use in CENTUM-series control systems. It ensures stable communication with field devices, provides secure signal processing, and includes integrated diagnostic features for reliable industrial automation performance.
General Information
Part Number: ADV869-P01
Manufacturer: Yokogawa
Series: ADV800 Series
Type: I/O Interface Module
Mounting: Installed in system I/O rack or base
Technology: Signal conditioning, electrical isolation, diagnostic monitoring
Power Specifications
Supply Voltage: Provided through system backplane
Power Consumption: < 6 W
Input Source: Backplane power feed
Protection: Isolation protection and overcurrent safeguards
Indicators: LED indicators for module health and signal status
Communication & Interface
System Bus: Yokogawa ESB/ICB bus
I/O Functions: Industrial analog/digital signal interfacing
Diagnostics: Self-diagnostics and channel monitoring
Operator Interface: LED indicators and configuration switches
Reset Features: Software reset or full system power reset
I/O & Channels
Channels: Supports dedicated or mixed industrial signal channels
Signal Support: Standard industrial-grade input/output formats
Isolation: Channel-to-system isolation
External Load: Not applicable (signal interface module)
Environmental
Operating Temperature: 0 to +55 °C
Humidity: Up to 90% RH (non-condensing)
Protection Rating: IP20 (cabinet installation required)
Dimensions & Weight
Dimensions (L × W × H): 130 × 127.2 × 32.8 mm
Weight: ~ 0.3 kg
