Overview
The Yokogawa AFV30D-S41152 S2 is an analog output module designed for the CENTUM VP distributed control system. It provides precise 4–20 mA output signals for actuators, valves, and other field devices, with integrated diagnostics and high reliability for safety-critical and process automation applications.
General Information
Part Number: AFV30D-S41152 S2
Manufacturer: Yokogawa
Country of Origin: Japan
Series: AFV30D
Type: Analog Output Module (AO)
Mounting: Rack or card installation in CENTUM VP chassis
Application: Process control, field device control, industrial automation
Power Specifications
Supply Voltage: Powered via system backplane
Output Type: 4–20 mA analog outputs
Load Capability: Supports standard field device loads
Protection: Short-circuit and overload protection, internal diagnostics
Power Consumption: Low module logic consumption
Communication & Interface
Interface Type: Backplane communication with CENTUM VP controller
Output Channels: Multiple analog outputs
Signal Type: 4–20 mA current signals
Diagnostics: Output health monitoring, fault detection, LED indicators
I/O & Channels
Output Type: Analog Output (AO)
Number of Channels: 4–8 channels (depending on system configuration)
Isolation: Galvanic isolation between module and field wiring
Signal Accuracy: High precision for process control
Environmental
Operating Temperature: 0 to +55 °C
Humidity: Up to 95% RH, non-condensing
Installation Environment: Industrial control cabinet
Protection Rating: IP20 (installed in rack enclosure)
Dimensions & Weight
Dimensions (L × W × H): 207 × 265.9 × 482.6 mm
Weight: 8 kg
