Yokogawa AFS40D-H4113 Field Control Unit

Overview

The Yokogawa AFS40D-H4113 is a duplex field control unit designed for industrial automation systems requiring high reliability and redundancy. It provides field-level process control, signal acquisition, and management for sensors, actuators, and other field devices. The unit ensures continuous operation, fast response times, and seamless integration with distributed control systems.

General Information

Part Number: AFS40D-H4113

Manufacturer: Yokogawa

Brand / Country of Origin: Yokogawa / Japan

Series: AFS Duplex Field Control Units

Type: Duplex Field Control Unit

Mounting: Panel or rack mounting in industrial control cabinets

Technology: Redundant field-level process control, high-speed signal processing, system integration support

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: ≤ 160 W

Input: Powered via field control cabinet

Protection: Short-circuit and overload protection

Indicators: LEDs for system status, redundancy, communication, and fault conditions

Communication & Interface

Bus Interface: Connects to distributed control systems for data exchange

I/O Channels: Multiple digital and analog inputs/outputs configurable for field devices

Diagnostics: System and channel-level fault detection, status reporting, and redundancy monitoring

Operator Interface: LED indicators for unit status, redundancy, and system health

Reset Features: Supports system-level and field-level reset

Environmental

Operating Temperature: 0 to +55 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20 for industrial cabinet mounting

Vibration & Shock: Conforms to IEC 60068 industrial standards

Dimensions & Weight

Dimensions (L × W × H): 207 × 265.9 × 482.6 mm

Weight: ~ 8 kg
