Overview
The Yokogawa AAV144-SM0 is a 16-channel isolated analog input module designed for accurate and stable signal acquisition in distributed control systems. It ensures high precision and reliability in industrial automation.
General Information
Brand: Yokogawa
Country of Origin: Japan
Model: AAV144-SM0
Type: Isolated Analog Input Module
Function: Converts voltage or current field signals into digital data for process control applications
Power Specifications
Input Signal: –10 V to +10 V voltage range or equivalent current inputs
Input Channels: 16 isolated analog input channels
Update Period: Typically 10 ms
Power Consumption: Low-power design optimized for continuous operation
Communication & Interface
Signal Type: Analog input signals
Connection: Compatible with 2-wire or 4-wire field devices
Interface: Standard Yokogawa I/O bus connection with self-diagnostic features
Environmental
Operating Temperature: –20 °C to +70 °C
Storage Temperature: –40 °C to +85 °C
Humidity: Up to 95% RH, non-condensing
Installation: Designed for use in control cabinets or DCS racks
Dimensions & Weight
Dimensions: 107.5 × 32.8 × 130 mm
Weight: 0.3 kg
