Overview
The ABB XV C768 AE101 (3BHB007211R0101) is an advanced control processor module designed for ABB’s industrial automation systems. It provides high-speed data processing, precise control execution, and reliable communication between controllers and field devices. This module is widely used in power generation, process control, and manufacturing automation, offering excellent performance and stability under continuous operation.
General Information
Brand: ABB
Country of Origin: Switzerland
Part Number: 3BHB007211R0101
Series: XV Series
Product Type: Control Processor Module
Mounting Method: Rack or chassis-mounted within ABB control systems
Function: Executes real-time control logic, communication handling, and system coordination
Technology: High-performance microprocessor with integrated communication and diagnostics features
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 15 W
Input Source: Supplied from the control system backplane
Protection Features: Overvoltage, short-circuit, and reverse polarity protection
Indicators: LEDs for power, communication activity, and fault status
Communication & Interface
Communication Ports: System bus, Ethernet / serial communication interfaces
Supported Protocols: Industrial fieldbus and ABB proprietary communication standards
Diagnostics: Built-in self-test, status monitoring, and fault detection
Configuration: Through ABB system configuration tools or engineering software
Reset Options: Supports both hardware and software reset functions
Environmental
Operating Temperature: 0 to +55 °C
Storage Temperature: −40 to +70 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20 (intended for cabinet installation)
Cooling Method: Natural convection air cooling
Dimensions & Weight
Dimensions (L × W × H): 240 × 140 × 85 mm
Weight: Approx. 1.6 kg
