GE IC200ALG260 | 8‑Channel Analog Input Module Rave reviews

Overview
The GE IC200ALG260 is an 8‑channel analog input module from the VersaMax series. It supports voltage (±10 V or 0–10 V) and current (4–20 mA) inputs, providing high-resolution signal acquisition for industrial automation and process control.

General Information
Brand: GE (General Electric)
Country of Origin: United States
Model Number: IC200ALG260
Series: VersaMax I/O Modules
Product Type: Analog Input Module
Application: Field sensor voltage or current measurement for PLC systems

Power Specifications
Supply Voltage: 5 V DC from backplane
Current Consumption: Approx. 130 mA
Input Ranges: Voltage: –10 V to +10 V, 0 to +10 V; Current: 4–20 mA
Resolution: 12‑bit
Update Rate: 0.4 ms per module

Communication & Interface
Channels: 8 single-ended input channels
Input Impedance: 126 kΩ in voltage mode, 200 Ω in current mode
Diagnostics: LEDs for internal power and module status; fault reporting for loss of internal power
Interface: VersaMax PLC backplane connection

Environmental
Operating Temperature: 0 °C to +60 °C
Humidity: Up to 95% RH, non‑condensing
Installation: Rack-mounted in industrial control cabinet

Dimensions & Weight
Dimensions (L × W × H): Estimated 120 × 30 × 110 mm
Weight: Approx. 0.26 kg
