Overview
The GE IS200DAMDG1A is a gate driver board designed for use in GE drive and turbine control systems. It controls the gating signals for power semiconductor devices, enabling safe and efficient operation of power conversion and motor drive applications.
General Information
Model: IS200DAMDG1A
Manufacturer: GE (General Electric)
Product Type: Gate Driver Board
System Platform: GE Drive and Control Systems
Application: Power electronics control, motor drives, and turbine systems
Power Specifications
Input Power: Supplied through the system backplane or dedicated power connector
Gate Output: Provides isolated gate drive signals to power devices (IGBTs, SCRs)
Protection Features: Includes short-circuit, overvoltage, and thermal protection
Signal Handling: Designed for high-speed switching with reliable timing characteristics
Communication & Interface
Interface Type: Multi-pin connectors for power module integration
Signal Types: PWM gating signals, feedback signals, and status communication
Compatibility: Interfaces with GE control processors and power modules
Diagnostics: Built-in status indicators for fault and operational monitoring
Environmental
Operating Temperature: 0 to 60°C
Humidity: Up to 95% RH, non-condensing
Design: Industrial-grade PCB with protective coating
Installation: Typically housed within the power converter or drive enclosure
Dimensions & Weight
Dimensions: 110 x 90 x 30 mm
Weight: Approx. 0.85 kg
