Overview
The GE DS200SHVIG1BGD is a high-voltage interface board designed for GE industrial drive systems, particularly within the Mark V series. It provides isolation, conditioning, and transmission of high-voltage signals, ensuring stable control and coordination between the power section and drive control electronics.
General Information
Part Number: DS200SHVIG1BGD
Manufacturer: GE (General Electric)
Series: Mark V / Industrial Drive Platforms
Type: High-Voltage Interface Board
Mounting: Rack or chassis installation
Technology: High-voltage isolation, signal conditioning, noise filtering
Country of Origin: United States
Power Specifications
Supply Voltage: Provided through the system backplane
Power Consumption: Low-power PCB electronics
Protection: High-voltage insulation, surge suppression, transient filtering
Indicators: May include test points for diagnostics
Communication & Interface
Interface Type: High-voltage signal interface
Functional Role: Transfers, conditions, and isolates high-voltage signals
Diagnostics: Supports signal verification and drive health monitoring
Operator Interface: Diagnostic test points
Reset Features: System-level reset via controller
I/O & Channels
Inputs: High-voltage sense and monitoring signals
Outputs: Conditioned signals to control boards
External Loads: None
Functional Purpose: High-voltage interface between drive control and power circuits
Environmental
Operating Temperature: −30 to +65 °C
Humidity: Up to 95% RH, non-condensing
Installation Environment: Industrial control cabinet
Dimensions & Weight
Dimensions (L × W × H): 330 × 200 × 40 mm
Weight: ~ 1.1 kg
