Schneider Electric Secures Patent for Analog Signal Output Circuit, Reducing Channel Redundancy, Pow
Time:2026-04-28 Browse: 0
[City, China – April 2026] – Schneider Electric Industrial Company has been granted a patent by the China National Intellectual Property Administration for an invention titled “Analog Signal Output Circuit, Processing Device, and Electronic Equipment” (Patent No. CN224154197U), originally filed in April 2025.
The patented technology introduces a compact and highly integrated analog signal output circuit. It comprises multiple resistors, an operational amplifier, and controllable switches, coordinated by a controller to switch between voltage mode and current mode. By optimizing the circuit design, the invention reduces channel redundancy, lowers power consumption, and decreases overall system cost, while maintaining precise signal processing.
This development reflects Schneider Electric’s commitment to innovating industrial electronics, enhancing efficiency, and providing high-performance solutions for automation and instrumentation applications. The technology is expected to benefit a wide range of electronic devices where signal accuracy, energy efficiency, and component miniaturization are critical.
