Overview
The Woodward 8200-1508 is an electronic speed controller module designed for precise engine speed regulation in industrial and marine engines. It provides accurate load sharing, droop compensation, and rapid response to load changes, ensuring stable and reliable engine operation.
General Information
Part Number: 8200-1508
Manufacturer: Woodward
Brand / Country of Origin: Woodward / USA
Series: 8200 Electronic Speed Controllers
Type: Electronic Speed Controller Module
Mounting: Panel or engine-mounted installation
Technology: Digital closed-loop control with programmable setpoints and fault diagnostics
Power Specifications
Supply Voltage: 12–32 V DC
Power Consumption: < 15 W
Input: Powered from engine control or auxiliary power supply
Protection: Reverse polarity and over-voltage protection
Indicators: LEDs for power, operation, and fault status
Communication & Interface
Interface Ports: Analog and digital inputs/outputs for speed sensors and actuators
Function: Maintains desired engine speed under varying load conditions and supports droop/load sharing control
Diagnostics: Built-in fault detection, alarm outputs, and speed deviation monitoring
Operator Interface: Configuration via Woodward software or manual adjustments
Reset Features: Supports soft reset and parameter re-initialization
I/O & Channels
Relay Channels: Optional relay outputs for alarms, shutdowns, or auxiliary control
External Load Support: Drives fuel actuators, solenoids, and auxiliary control devices
Environmental
Operating Temperature: –40 to +85 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP65 with proper enclosure or installation
Dimensions & Weight
Dimensions (L × W × H): 160 × 110 × 65 mm
Weight: ~1.0 kg
