Overview
The ABB AO561 is a robust and precise Analog Output Module designed for use in industrial automation systems. It is responsible for converting digital control signals into high-accuracy analog outputs, which can then be used to control various field devices, such as actuators and valves. The AO561 is suitable for complex applications in process control, energy management, and manufacturing, offering excellent signal accuracy, stability, and seamless integration into control systems.
General Information
Part Number: 1TNE968902R1201
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: AO (Analog Output)
Type: Analog Output Module
Mounting: Designed for installation in control panels, automation racks, or system enclosures
Technology: Digital-to-analog signal conversion for industrial applications
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 8 W
Input: Powered from system backplane or external DC supply
Indicators: LEDs for power, output status, and fault indication
Protection: Over-voltage, over-current, and short-circuit protection
Communication & Interface
Interface Type: Backplane and industrial communication protocols
Signal Handling: Converts digital control signals to analog output for field devices
Diagnostics: Built-in diagnostics for output status, signal integrity, and fault detection
Reset Features: Supports module and system-level reset functions
Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20, suitable for industrial environments
Dimensions & Weight
Dimensions (L × W × H): 93 × 63 × 170 mm
Weight: ~ 0.3 kg
Authentic parts with full manufacturer warranty.
