Overview
The HIMA Z7138/3330/C5/P2/R is a safety controller module designed for use in HIMA HIMax and HIQuad safety instrumented systems (SIS). It provides high-performance processing for safety-critical applications, enabling reliable monitoring, logic evaluation, and fault-tolerant control of industrial processes.
General Information
Part Number: Z7138/3330/C5/P2/R
Manufacturer: HIMA
Series: HIMax / HIQuad
Type: Safety Controller / CPU Module
Mounting: Rack-mounted within HIMA safety system chassis
Technology: SIL-rated processor with redundant logic channels and self-diagnostics
Power Specifications
Supply Voltage: 24 V DC (via backplane)
Power Consumption: ≤ 15 W
Power Source: Redundant backplane supply supported
Protection: Over-voltage, surge protection, short-circuit protection
Indicators: LEDs for power, status, fault, and communication
Communication & Interface
Interface Type: Redundant internal bus for I/O modules
Field Communication: Supports HIMA serial and network interfaces for field devices
Diagnostics: Continuous self-monitoring, communication fault detection, system diagnostics
Configuration: Programmed and configured via HIMA engineering tools
Reset Options: Supports software reset and hot-swapping within redundant systems
I/O & Channels
Module Role: Central processing and control
Supported I/O: Works with discrete input, discrete output, analog, and communication modules
Redundancy: Dual-CPU or channel-redundant configurations for high availability
Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Suitable for installation in standard industrial control cabinets
Dimensions & Weight
Dimensions (L × W × H): Approx. 180 × 40 × 125 mm
Weight: ~ 0.7 kg
